20 Tons factory material handling equipment iron casting plant
transports
The electric flat car is now used as a general factory handling
equipment, bringing many convenience to the factory handling. It is
used in many industries such as workshop transfer, mold handling,
shipping, heavy industry, etc. Facing the use of different
environments or special occasions, materials are particularly
important. Bad materials will not only be scrapped in a few years,
but more importantly, this hidden danger is particularly easy to
threaten the personal safety of staff and cause accidents. The
areas and environments involved in these industries are different.
Some work at high temperature and some are used in explosion-proof
situations. Without exception, these handling equipment have very
high requirements for materials. For example, the iron casting
plant transports hundreds of degrees Celsius of molten steel back
and forth every day. Poor materials do not need to be verified for
a long time. They will show signs in succession. They will probably
not be easily purchased before confirming the materials, And use
the product.
| RWP Technical parameters for electric transfer carts |
| 1 | rated load(t) | 5 | 10 | 15 | 20 | 30 | 40 | 50 | 150 |
| 2 | impacted rated load(t) | 7.5 | 15 | 22.5 | 30 | 45 | 60 | 75 | 225 |
| 3 | structure of frame | steel plates welded, beam structure |
| 5 | ground requirement | cement floor | steel plate ground |
| | | |
| 6 | table size(mm) | 3000×2000 | 3600×2000 | 4000×2200 | 4500×2200 | 5000×2200 | 5500×2300 | 6000×2300 | 10000×3000 |
| 8 | ground clearance(mm) | 0-100 | 75 |
| 10 | axles distance(mm) | 2500 | 3100 | 3400 | 3900 | 4300 | 4800 | 5200 | 10000 |
| 11 | turning radius(mm) | 2501 | 3101 | 3401 | 3901 | 4301 | 4801 | 5201 | 10001 |
| 12 | turning type | turning while driving with no stop |
| 13 | control method for turning | control button |
| 14 | turning structure | mechanical |
| 16 | wheel diameter(mm) | Ф300 x 4 | Ф350 x 4 | Ф400 x 4 | Ф400 x 6 | Ф500 x 6 | Ф600 x 8 |
| 22 | battery maintenance | free of maintenance |
| 23 | charger's installation | installed on cart | split-type |
| 24 | charger function | automatic charging |
| 26 | warning equipment | sound and light |
| 27 | other functions | power display |
We are a professional manufacturer of electric flat cars.
One-to-one communication and coaching can be carried out by
specially-assigned persons. According to different on-site
operation conditions, we can customize various tonnage electric
flat cars that meet the needs of on-site work, including various
non-standard special vehicles, such as steel ladle cars,
sandblasting and painting room cars, ferry cars, split cars,
turntables, etc.
