    Conveyor Industrial Transfer Carts Omnidirectional Load Transfer Trolley

    Ask Lasest Price
    Brand Name : Remarkabl
    Model Number : RWP/AGV
    Certification : ISO9001,ISO14001,ISO45001,CE
    Payment Terms : L/C, T/T
    Supply Ability : 500 sets/year
    Delivery Time : 40 days
    • Product Details
    • Company Profile

    Conveyor Industrial Transfer Carts Omnidirectional Load Transfer Trolley

    Industrial Conveyor transfer cart Industrial Conveyor transfer cart

    The electric driven Remarkable industrial conveyor transfer cart is designed to move up to 500 tons of heavy goods, and is used for continuous movement of goods and goods requiring long-distance movement.

    This type of electric transfer cart works outdoors and usually has a multi-directional direction to provide very small turns. Like all Remarkable carts, these are customized according to customer requirements. Ideal for working in shipyards, steel mills or wind power plants.

    Remarkable designed and industrial transfer cart and provide innovative handling solution with more than 17 years' experience.The transfer cart can be used in industry plant, port, workshop, production line and so on to transport ladle, coil, mold, steel products,workpiece and so on.All the solution are designed as per customers true demand.Wired operate electric workshop steel electric transfer cart.



    Remarkable battery powered Industrial Conveyor transfer cart is a good choice if meeting the following features:

    1.The running distance is not limited

    2.Low using frequency(The spare battery can be provided if higher using frequency)
    3.Despite of turning or going straight, the rail trolley can realize

    4.Despite of running on indoor or outdoor, high temperature or explosive environment, ferry or cross rail, the transfer trolley can realize.

    5.Dimensions,capacity, loading platform superstructure, speed and many others special function can be customized as per client request.

    Technical parameters for trackless electric transfer carts
    rated load(t)5101520304050150
    impacted rated load(t)7.51522.530456075225
    structure of framesteel plates welded, beam structure
    max. wheel load(t)2.84.34.85.67.7101227
    ground requirementcement floorsteel plate ground
    table size(mm)3000×20003600×20004000×22004500×22005000×22005500×23006000×230010000×3000
    height of the whole cart(mm)4505306006006507007001200
    ground clearance(mm)5075
    wheels base(mm)1500170018002000
    axles distance(mm)250031003400390043004800520010000
    turning radius(mm)250131013401390143014801520110001
    turning typeturning while driving with no stop
    control method for turningcontrol button
    turning structuremechanical
    motor power(Kw)3.556710121515
    wheel diameter(mm)Ф300 x 4Ф350 x 4Ф400 x 4Ф400 x 6Ф500 x 6Ф600 x 8
    wheel materialZG55+hydropur ture
    running speed(m/min)0-150-12
    brake principleelectric magnetic brake
    operation methodwith wire or no wire
    battery modelD-250 x 24D-33 x 24D-400 x 24D-440 x 24D-250 x 36D-330 x 36D-440 x 36D-600 x 36
    battery maintenancefree of maintenance
    charger's installationinstalled on cartsplit-type
    charger functionautomatic charging
    radar control3-0.3m, automatic stop for obstacles
    warning equipmentsound and light
    other functionsturning light, night light and power display
