    10 Tons Trackless Electric Transfer Cart For Material Handling

    Ask Lasest Price
    Brand Name : Remarkabl
    Model Number : RWP/KPX/RGV/AGV
    Certification : ISO9001,ISO14001,ISO45001,CE
    Payment Terms : L/C, T/T
    Supply Ability : 500 sets/year
    Delivery Time : 40 days
    • Product Details
    • Company Profile

    10 Tons Trackless Electric Transfer Cart For Material Handling

    10 Tons Trackless Electric Transfer Cart

    The 10 tons trackless transfer cart designed and produced by Ruimaike is exported to Bulgaria. A track flat cart is a type of rail transport cart that can operate on S-shaped or curved tracks, as well as on a combination of straight and curved tracks, and on intersecting tracks.

    This series of electric flatcars has a simple structure, is safe and flexible, suitable for heavy loads, high frequency of use, can achieve full automation, is easy to maintain, has a long service life, is explosion-proof, has low noise, and is safe and environmentally friendly. It is widely used in heavy industry, machinery manufacturing, petroleum, metallurgy, mining, chemical industry, shipbuilding, coal, electromechanical, aerospace equipment, military industry and other industries.

    Rated Loading capacity(t):10

    Table size(mm):5800*1500 (L*W)

    Cart height(mm):700

    Operation method:Wireless remote control & Hand operate pendant

    Safety device:Audible and visual alarm lamp and emergency stop button,laser scanner

    Technical parameters for trackless electric transfer carts
    rated load(t)5101520304050150
    impacted rated load(t)7.51522.530456075225
    structure of framesteel plates welded, beam structure
    max. wheel load(t)2.84.34.85.67.7101227
    ground requirementcement floorsteel plate ground
    table size(mm)3000×20003600×20004000×22004500×22005000×22005500×23006000×230010000×3000
    height of the whole cart(mm)4505306006006507007001200
    ground clearance(mm)5075
    wheels base(mm)1500170018002000
    axles distance(mm)250031003400390043004800520010000
    turning radius(mm)250131013401390143014801520110001
    turning typeturning while driving with no stop
    control method for turningcontrol button
    turning structuremechanical
    motor power(Kw)3.556710121515
    wheel diameter(mm)Ф300 x 4Ф350 x 4Ф400 x 4Ф400 x 6Ф500 x 6Ф600 x 8
    wheel materialZG55+hydropur ture
    running speed(m/min)0-150-12
    brake principleelectric magnetic brake
    operation methodwith wire or no wire
    battery modelD-250 x 24D-33 x 24D-400 x 24D-440 x 24D-250 x 36D-330 x 36D-440 x 36D-600 x 36
    battery maintenancefree of maintenance
    charger's installationinstalled on cartsplit-type
    charger functionautomatic charging
    radar control3-0.3m, automatic stop for obstacles
    warning equipmentsound and light
    other functionsturning light, night light and power display
